Plug and Play Filtered Power Supplies

Clean Power

Elite EMC Provide a range of customisable Filtered Power Supplies (AC-DC & DC-DC). We use existing parts and building blocks reducing lead-time and costs that allow us to offer completely customisable solutions that are designed to meet a range of Military and Defence standards. Test Data available.

Filtered Power Supplies
Filtered Power Supplies

Features and Benefits

Our solutions utilize low noise, fixed frequency, wide input Voltage range (9V to 60V) topology with extended high and low input transient capability and integrated EMI filtering to ease system integration and compliance. Our Ruggedized systems are built for the harshest of environments and utilize specialist components which have been tested to JESD22, MIL-STD-810 and MIL-STD-883.

Custom housing and enclosures

All of our solutions have the option to be housed in custom specific housings. Filters designed to be fitted post production to Military vehicles for example usually have limited and non-standard available space. Our custom machined enclosures allow us to use every available amount of space available offering improved filter performance and thermal management.  We can also produce housings to replicate an existing unit in case of obsolescence. As well as the space envelope we can also offer a range of materials, finished and even colours if required.

Filtered Power Supplies
Custom Filter Solutions

Input / Output and cabling

As the majority of our products are connected to our customers products post production we offer a range of I/O terminations. For proof of concept samples we usually build our units with flying leads or studs to allow quick testing. Once the unit has been approved we can then fit connectors or whatever is required to plug directly into the customers unit. As well as having the I/O altered we can also offer harnessing to accompany the PSU if required.

Thermal Management

By nature of their design EMI Filters and PSU’s usually produce a relatively large amount of heat. During the design process our engineering teams will work closely with the customer to identify potential heat issues and bring this into the design phase early on to prevent issues later. We can implement thermal protection such as thermal cut-out switches to protect the products during unexpected heat rises. If the customer’s end product does not have cooling in place we can customize the housing to include heat sinks or fins

Features

  •  Wide input voltage range
  • Single, Dual, triple outputs
  • 3.3V,5V,12V,15V,18V,28V as standard, others on request
  • Integrated EMI Filtering
  • Completely customisable
  • Optional cables and accessories
  •  Various pricing scales / options
  • Rapid Prototypes

Designed to Meet



  • DO-160
  • MIL-STD-461
  • MIL-STD-1275
  • DEF STAN 59-411
  • DEF STAN 61-5 Part 6 Issue 6
